Custom Piping Solutions for Data Centers

Built for the AI Surge. Resilient piping solutions to support, protect and secure your cooling infrastructure

From hyperscale new builds to complex legacy retrofits, we deliver the integrated piping technology required for high-density liquid cooling and chilled water loops. Ensure zero downtime with pre-insulated supports, seismic-rated expansion joints, and comprehensive pipe stress analysis.

The Evolution Of Data Center Piping Standards

As sites become more crowded and cooling loads increase, standard piping designs often fail to meet space and safety constraints. Discover how engineering standards are adapting to challenges like differential settlement and the need for compact, seismic-resilient infrastructure.

Three specialized brands. One integrated solution for Data Center Mechanical Systems.

Thermal & Seismic Management

Featured Brand: US Bellows Products: Expansion Joints, U-Loop Pipe Loops

Data centers are crowded environments. Our nested U-Loop pipe loops feature an industry-first hybrid design that integrates bellows directly into the loop structure. We also make flex connectors and metallic expansion joints in addition to U-loops. This allows for superior flexibility handling both thermal expansion and seismic movement while minimizing the footprint on crowded jobsites. We are the fastest and lowest cost time-to-market solutions for large scale, fast-paced products.

The single pipe expansion joint is simply a bellows element with end connections. Regardless of accessories, it will deflect in any direction or plane that the bellows will. It requires that the piping be controlled as to the direction of the movements required of the unit. The pipe expansion joint should not be expected to control the movement of the pipe, and will not resist any deflections with any force other than the resistance of the bellows.

Developed for one of the largest automotive manufacturing campuses in the United States, our custom nested U-Loop expansion joints represent a breakthrough in industrial piping support. When tasked with securing a 2.3-square-mile battery plant against seismic activity, US Bellows delivered an industry-first solution: U-Loops integrated with bellows.

Space-Saving Design

Nested configurations prevent "clunky" expansion joints from colliding during seismic activity, optimizing valuable floor and rack space.

Differential Settlement

Engineered to absorb ground movement and settlement rates between buildings, ensuring pipeline integrity for mission-critical cooling loops.

Cold Piping Integrity

Featured Brand: Pipe Shields Products: Pre-Insulated Pipe Supports

Protect your chilled water loops from thermal bridging and condensation. Our pre-Insulated pipe supports are designed to maintain the vapor barrier, preventing moisture damage to sensitive electrical equipment and ensuring maximum energy efficiency in high-demand cooling systems.

Insulated pipe supports are designed to prevent direct heat transfer between pipes and their supports. Thus, they reduce heat loss due to conduction at each support.

Ideal for Retrofits

Full pipe stress analysis and PE stamping to ensure safety and compliance.

Condensation Control

Eliminates the "sweating" common in standard supports, protecting server hardware below.

Vibration Control & Structural Safety

Featured Brand: Piping Technology & Products Products: Pipe Supports, Guides, Anchors, Variable Springs, Pipe Stress Analysis

Liquid cooling introduces complex vibration and weight challenges. We provide the hardware and the engineering logic to secure it. From pipe guides and anchors that manage vibration in chilled water loops to pipe stress analysis that validates your design before construction begins, we ensure your facility withstands the static and dynamic loads of modern cooling infrastructure.

Pipe shoes and pipe guides are available in a variety of designs. Slide plates may be included on the pipe shoes for smooth sliding. Custom pipe shoes and anchors can be designed to meet your specific design requiremen

Anchor bolts are special high-strength bolting used to secure equipment to the foundation. We can supply anchor bolts in various alloy materials or carbon steel, with either a plain finish or a hot-dipped galvanized finish. Embeds are essentially anchor bars used to secure the embed steel into the concrete. Embeds are usually fabricated with carbon steel with a hot-dipped galvanized finish. We also supply open steel grating with various mesh configurations in relation to baring bars and cross bars, which are used for decks, walkways, floors, catwalks, runway and fire escapes.

Variables use coiled springs to support a load and allow movement. The resistance of the coil to a load changes during compression, which is why these devices are called “variables”. We offer a variety of different designs of variable spring pipe supports.

Engineering Services

Easily integrates into existing chilled water systems where insulation integrity is paramount.

Vibration Management

Specialized anchors and guides designed to dampen noise and vibration in high-velocity cooling loops.

Engineering Insights for Critical Facilities

Understanding the pain points of modern data center operators—from retrofitting to AI-ready cooling.

The Shift to Liquid Cooling

Powering High-Density Data Centers for the AI Era As rack densities increase for AI workloads, air cooling is no longer sufficient. Learn how piping infrastructure must evolve to support the weight and complexity of liquid cooling systems.

Retrofitting Legacy Facilities

Integrating New Cooling into Old Spaces Don’t build new if you don’t have to. Discover the engineering strategies for fitting modern, high-capacity cooling loops into the constrained footprints of legacy data centers.

Managing System Noise & Movement

The Role of Pipe Guides and Anchors in Cold Piping Vibration is the enemy of data integrity. This guide details how to correctly apply anchors and guides to stabilize chilled water loops and prevent mechanical failure.

Specialized Fluid Handling

Engineering Guide: Expansion Joints for Dielectric Fluid Loops Dielectric fluids used in immersion cooling behave differently than water. Ensure your expansion joints are compatible with these specialized fluids to prevent leaks and contamination.
