Trapeze Roller Hangers for a Food Processing Facility
December 3, 2024

Trapeze Roller Hangers For A Food Processing Facility

Type: Trapeze Roller Hangers
Size: 2-5/8″ to 16-3/8″ L x 4″ to 16″ Dia. | 600 to 3,970 lb. Load
Material: Cast Iron
Testing: Standard quality control inspections

Piping Technology & Products designed these trapeze roller hangers for a food processing facility in Kentucky. Rollers are typically employed when axial movement at the support location results in swing angles exceeding 4 degrees.

The rollers are available in lengths ranging from 2-5/8″ to 16-3/8″ for pipe diameters between 4″ and 16″. Constructed with cast iron rolls and sockets along with steel roll rods, they ensure durability and adaptability for a range of applications.

The rollers are oriented horizontally for the suspension of pipes using two all threaded vertical rods and hex nuts for vertical adjustments, effectively accommodating longitudinal movement caused by thermal expansion or contraction. They are designed for load ratings ranging from 600 to 3,970 lbs.

Standard quality control inspections were conducted prior to shipment to ensure compliance with industry standards. Similar applications by Piping Technology & Products include:

  • Wastewater facilities
  • Food Service
  • Bridges
  • Cooling Towers
  • Refineries
  • Gas Plants

In addition to standard rollers, we offer machinable rollers made from specialized non-metallic materials, such as polyurethane and polyurethane foam. These materials can be custom-contoured to meet unique project specifications using our in-house manufacturing capabilities.

For larger roller assemblies, Piping Technology & Products provides complete customization options, including finite element analysis (FEA) to ensure the design meets the exact requirements of your piping system. Whether you need standard or customized solutions, our team is equipped to deliver quality products tailored to your application.

PT&P REF. ORIGINAL POST 04242017

Read More

14” Diameter Pipe Shoe Assemblies for a Refining Project in Saudi Arabia
April 2, 2024

14” Diameter Pipe Clamp Assemblies Designed And Manufactured By Pt&Amp;P For A Refining Project In Saudi Arabia

Piping Technologies & Products fabricated these special designed Split-T pipe shoes using a Figure 50 “two-bolt pipe clamp” with added gusset plates welded beneath the clamps for a refining project in Saudi Arabia. The gusset plates are added to increase the vertical load-carrying capacity. The pipe shoes are 4″ height x 15.5″ wide x 18″ long and were fabricated from A36 carbon steel with a hot-dipped galvanized finish. They are designed for a pipe size of 14″ with an operating temperature from -29°C to 316°C. The pipe shoes are capable of supporting an operating load of 34,000 lb.



We provide such products in a “clamp-on-shoe” configuration to meet the needs of client applications where welding the pipe shoe onto the process line is prohibited. Depending on the client’s specifications, we can design and manufacture these shoes without a finish (black) or various painted finishes in place of hot-dipped galvanizing to expedite the delivery of the order. We can manufacture these clamp-on-pipe shoes with different metallurgies, such as 304 or 316 stainless steel, to accommodate high temperatures or cryogenic applications depending on the project’s needs. This basic pipe support is used in industries ranging from automotive, petrochemical, LNG, and refining in almost every major processing unit to maintain pipe elevations and handle loads imposed by media movement.

PT&P REF. ORIGINAL POST 07112016

Read More

PT&P Roller Hangers for an Aviation Facility in California
December 26, 2023

Pt&Amp;P Roller Hangers For An Aviation Facility In California

Type: Roller Hangers
Size: 12″ Wide and 15″ Tall
Material: Cast Iron & Carbon Steel
Design: 965 lbs. Operating Load & 10″ Pipe Size
Testing: Standard Quality Control

These Fig. 195 roller hangers were designed by PT&P for an aviation facility in California. They measure 12″ in width and 15″ in height. The rollers are fabricated from cast iron, with the yoke, roll rod, and hex nuts from carbon steel. The units are designed for a pipe size of 10″ and an operating load of 965 lbs. Standard quality control tests were performed prior to shipment. Roller hangers are used for the suspension of pipe from a single rod where axial movement may occur because of expansion or contraction. These are often used on bridges where pipelines cross waterways such as rivers and bayous. If there is extensive traffic, they can be used in conjunction with variable springs to accommodate such factors as vibration, wind, and other external factors. This particular job is an excellent demonstration of our ability to support quick turn request to meet the needs of our clients as it was shipped before the contract date in less than a week’s time.

Our roots are deeply embedded in the petrochemical, power, energy, and refining sectors. We remain adaptable, constantly seeking opportunities to contribute to pivotal projects. Our recent diversification into various industry verticals encompasses participation in both private and public sector space exploration. Additionally, we play a pivotal role in the flourishing 11.2 billion-dollar data center industry, driven by advancements in AI and its widespread adoption.

Time-to-market is a paramount consideration for our projects. Leveraging our Houston-based manufacturing facility, we stand out as a market leader, possessing the capability to support large volumes within tight timeframes. This agility is particularly crucial for the time-sensitive nature of semiconductor, pharmaceutical, EV battery, and automotive production facilities.

PT&P REF. ORIGINAL POST 04022018

Read More

Standard Pipe Support Components Available on Amazon
September 21, 2022

Need a standard product quickly? Or know what you need and don’t need a quote? Skip the line and order through Amazon. From forged carbon steel turnbuckles and light or heavy 2-bolt, 3-bolt pipe clamps, riser clamps to long tangent u-bolts, we stock standard sizes for your quick-turn orders.

*If you need assistance, we are always available 24×7 via our emergency service or just send an email to info@pipingtech.com.



Ptp Fig30 Forgedcsturnbuckle
Fig. 30 Forged Carbon Steel Turnbuckle		 Ptp Fig60 Heavy 2 Bolt Pipe Clamp
Fig. 60 Heavy Two-Bolt Pipe Clamp
Ptp Fig70 Light 3 Bolt Pipe Clamp
Fig. 70 Light Three-Bolt Pipe Clamp		 Ptp Fig80 Heavy 3 Bolt Pipe Clamp
Fig. 80 Heavy Three-Bolt Pipe Clamp
Ptp Fig90 Riser Clamp
Fig. 90 Riser Clamp		 Ptp Fig100 Long Tangent U Bolt
Fig. 100 Long Tangent U-Bolt
Ptp Fig90 Riser Clamp
Piping Technology & Products, Inc. Expansion Joint (85 PSI)		 Ptp Fig100 Long Tangent U Bolt
Piping Technology & Products, Inc. Expansion Joint (150 PSI)
Ptp Fig90 Riser Clamp
Piping Technology & Products, Inc. Expansion Joint (300 PSI)
Read More

Pipe Saddles Custom Designed for LNG Facility
August 3, 2022



Pipe Saddles Custom Designed For A Large Liquefaction Project At An Lng Facility

Type: Heavy-Duty Pipe Saddles
Size: Up to 48” Diameter
Material: A36 Carbon Steel
Testing: Q.C. Visual Inspection | Pipe Dimensional Tests

This week’s featured product, Piping Technology & Products, Inc. custom-designed heavy-duty pipe saddles for an LNG facility in Louisiana. The pipe saddles are part of a large liquefaction project and range in size. The largest pipe saddle will support a 48” diameter pipeline. They are fabricated utilizing A516 Gr70N low-temperature carbon steel base plates, and web plates. Standard Q.C., visual inspection with pipe dimensional tests were performed prior to shipment. A pipe saddle is a structure consisting of a saddle and integral base used to support the pipe by transmitting the load or forces to the adjacent structure. Since we are a custom fabrication shop, we specialize in the design and manufacture of pipe shoes and saddles to accommodate sloping lines, pipe elbows, hot and cold temperature lines, as well as storage tanks and pressure vessels. In addition to pipe saddles, we have also supplied a wide variety of pipe supports to LNG projects, as well as, Floating Rings. Below is just a brief list of supports supplied to LNG projects from our product portfolio:

Varibale Assemblies

Constants Assemblies

Pipe Hanger Hardware

Slide plates and wear pads

Snubbers, Sway braces

Cryogenic Insulated Shoes-G10 as well as PUF

Insulated Trunnions

Adjustable Pipe Stands

Our products have gone into all key components of LNG facilities ranging from the liquefaction plant, the flare lines, loading lines, the terminals, and storage tank facilities.

PT&P REF. ORIGINAL POST 01082020

Read More

Heavy-Duty Pipe Clamps for Service at a Coal-Fired Power Plant
April 26, 2022

Heavy-Duty Pipe Clamps For Service At A Coal-Fired Power Plant

These clamps were installed in a coal-fired power plant on the Ohio River and this plant features one of the largest smokestacks in the world at 1038 feet. For this plant, sub-bituminous coal is used in conjunction with steam turbine technology to generate thermal power with over 10k Gigawatts of output annually.

Heavy-duty pipe clamps are bolted around the pipe and connect to the remainder of the pipe hanger assembly. This assembly included a Fig. 30 Forged Turnbuckle, which is also available on Amazon as a stocked item. PT&P maintains an extensive inventory of pipe clamps required for pipe hangers and support assemblies. These Fig. 80 Three-Bolt Pipe Clamps are fabricated from carbon steel and for this project, the pipe clamps were painted with a red oxide primer. These pipe clamps are designed for 36” diameter pipelines and are recommended for suspension of cold pipelines or hotlines where little or no insulation is required and are capable of supporting both horizontal and vertical piping. A visual inspection test along with “sample pipe” dimensional checks were conducted prior to shipment.

Such clamps can be used in any type of piping system for various industries such as chemical, biofuel, food processing, and refining plants. We have the ability to get such products at your jobsite overnight given our pipe hanger hardware inventory of over 1 million pounds, our quick order system through Amazon, and 24/7 manufacturing and engineering support provided by our teams around the clock.

Do you need this exact pipe support? Skip the line and order our Standard Pipe Support Components on Amazon. From forged carbon steel turnbuckles and light or heavy 2-bolt, 3-bolt pipe clamps, riser clamps to long tangent u-bolts, we stock standard sizes for your quick-turn orders.

Read More

Structural Supports Custom Designed for a Liquefaction Project
May 22, 2017

Structural Supports Custom Designed For A Liquefaction Project

Type: Structural Supports
Size: 6″ x 12″ to 6″ x 18″
Material: Carbon Steel with HDG Finish
Testing: Standard Q.C. Inspection

Piping Technology & Products custom designed these structural supports to provide base support for pipes at a liquid natural gas (LNG) facility in Louisiana. The supports are fabricated from carbon steel with a hot-dipped galvanized finish. Sizes range from 6″ x 12″ to 6″ x 18″ and all supports underwent a quality control inspection prior to shipment.

Read More

Type-C Variable Assemblies with Dual Travelers for a De-coker Unit
December 22, 2016

Type-C Variable Assemblies With Dual Travelers For A De-Coker Unit

Type: Variables with dual travelers
Design: Operating load: 1,698-21,756 lbs
Material: A36 Carbon Steel with HDG finish
Size: Horizontal Travelers range from size 2 to size 4

These dual travelers with Type-C variable spring hanger assemblies were custom designed by Piping Technology & Products for valves in a de-coker unit in Texas. All completed assemblies were fabricated from A36 carbon steel with an HDG finish. The travelers range from size 2 to size 4 and are designed for 12″ of horizontal movement. The variables are designed for an operating loads ranging from 1,698-21,756 lbs.

Read More

Custom Designed Pipe Clamp and Sway Strut Assemblies for an Ethane Cracker Facility in Texas
December 12, 2016

Custom Designed Pipe Hanger And Pipe Clamp Assemblies For An Ethane Cracker Facility In Texas

Type: Pipe Clamp and Sway Strut Assemblies
Design: Operating load: 99,650 lb. | Temperature: 550°F
Material: A36 Carbon Steel
Size: Clamps: 149″ L x 14″ W x 2″ T | Load Bolt: 4-1/2″ | 68″ Dia. Pipe

Piping Technology & Products custom designed pipe clamp and sway strut assemblies assemblies for an ethane cracker facility in Texas. The clamps are designed for a 68″ diameter pipe using a bar size of 149″ long x 14″ wide x 2″ tall. The load bolt size is 4-1/2″ and the inside bolts, rods, nuts, and turnbuckle are 4″ diameter. The assemblies are completely fabricated from A36 carbon steel, and designed for an operating temperature of 550°F with a load capacity up to 99,650 lb. A visual inspection test with sample pipe and dimensional check were conducted prior to shipment.

Read More

PT&P Designed Pipe Roller Stands for a Wastewater Treatment Plant
November 7, 2016

Pt&Amp;P Designed Pipe Roller Stands For A Wastewater Treatment Plant

Type: Pipe Roller Stands
Design: 1,000 lb. Load | 30″ Dia. Pipe | 18-3/4″ x 13″ x 10-3/16″ BOP
Material: Stainless Steel
Function: For support of piping that expands and contracts longitudinally and where vertical adjustment is not necessary.

Piping Technology & Products, Inc. designed pipe roller stands fabricated from stainless steel for a wastewater treatment plant. Each roller has two spring housings with eight springs in each. They are designed for an operating load of 1,000 lb. on a 30″ diameter pipeline. The rollers measure 18-3/4″ x 13″ x 10-3/16″ BOP and went through quality control inspection and tests prior to shipment.

Read More
